Fixing Viam Graph Error With ISS Register Alias

This article delves into a specific error encountered while using the Instruction Set Simulator (ISS) when registering an alias, leading to a Viam Graph error. We will explore the error message, dissect the code snippet that triggers it, and discuss potential solutions and debugging strategies. Whether you're a seasoned developer or just starting with VADL (Viam Architecture Description Language), this guide aims to provide a comprehensive understanding of the issue and how to resolve it.

Understanding the Viam Graph Error

The error message, vadl.viam.graph.ViamGraphError: applier produced a null node for apply(). Checkout the implementation of the from-node, you probably want to use applyNullable for the Nullable field., indicates a problem within the Viam Graph framework. Specifically, the error arises when the system attempts to apply a node that results in a null value, and the applyNullable method was expected but not used. This usually points to an issue in how nodes are being connected or how data is being transformed within the graph.

Decoding the Error Message

Let's break down the error message further:

  • vadl.viam.graph.ViamGraphError: This signifies that the error originates from the Viam Graph library.
  • applier produced a null node for apply(): This is the core of the problem. An "applier," which is responsible for transforming and applying nodes within the graph, has produced a null node when a non-null node was expected.
  • Checkout the implementation of the from-node, you probably want to use applyNullable for the Nullable field: This is a crucial hint. It suggests that the node causing the issue might be a Nullable field, and the applyNullable method should be used to handle potential null values gracefully.
  • The subsequent lines (with node: (i) DynSlice<Bits<4>>, with node: (i) BuiltInCall<Bits<5>, VADL::sub(BitsType, BitsType) -> BitsType>, with location: unknown:0..0, with source: Invalid source location: unknown:0..0) provide context about the specific nodes and locations involved in the error. This information is invaluable for pinpointing the exact source of the problem.

The Code Snippet Triggering the Error

The provided VADL code snippet defines an instruction set architecture (ARCH) and a processor (EXAMPLE) that implements it:

instruction set architecture ARCH = {

  program counter PC  : Bits<64>
  memory          MEM : Bits<64> -> Bits<8>

  register CR  : Bits<32>
  alias register CRF : Bits<8><4> = CR

}

processor EXAMPLE implements ARCH = {
  reset = PC := 0x0000'0000'0000'0000

  [ firmware ]
  [ base: 0x00000000 ]
  memory region [RAM] DRAM in MEM
}

Dissecting the Code

  • Instruction Set Architecture (ARCH): This section defines the architecture's components:
    • program counter PC: A 64-bit register representing the program counter.
    • memory MEM: A memory space that maps 64-bit addresses to 8-bit values.
    • register CR: A 32-bit register.
    • alias register CRF : Bits<8><4> = CR: This is the key line causing the error. It defines an alias CRF for the CR register. CRF is an array of four 8-bit fields, effectively creating a view of the 32-bit CR register as four individual bytes. This slicing and aliasing operation seems to be the root cause of the ViamGraphError.
  • Processor (EXAMPLE): This section defines a processor that implements the ARCH architecture:
    • reset = PC := 0x0000'0000'0000'0000: Sets the initial value of the program counter to 0.
    • memory region [RAM] DRAM in MEM: Defines a memory region named DRAM within the MEM memory space.

Identifying the Root Cause

The error likely stems from how the DynSlice node, used to implement the CRF alias, interacts with the Viam Graph. The DynSlice node is responsible for extracting a slice (in this case, an 8-bit chunk) from a larger data structure (the 32-bit CR register). The error message suggests that the DynSlice node might be producing a null value under certain circumstances, and the system is not handling this null value correctly.

The alias definition alias register CRF : Bits<8><4> = CR attempts to create a multi-dimensional view (Bits<8><4>) of the CR register. The Viam Graph likely has a mechanism to handle slices and sub-fields, but the combination of aliasing and slicing might expose a bug or an unhandled edge case in the graph's node application logic.

Debugging Strategies and Potential Solutions

To resolve this issue, we need to dive deeper into the Viam Graph's internals and understand how it handles register aliases and slicing operations. Here are several debugging strategies and potential solutions:

  1. Examine the DynSliceNode Implementation: The error message explicitly mentions the DynSliceNode. A thorough review of its implementation in the Viam Graph library is crucial. Pay close attention to how it handles null values and whether it correctly utilizes applyNullable when necessary.
  2. Simplify the Code: Try simplifying the VADL code snippet to isolate the problem. For instance, remove the memory region definition or the processor reset logic. If the error disappears, it indicates that the issue might be related to the interaction between the register alias and other parts of the specification.
  3. Modify the Alias Definition: Experiment with different ways of defining the alias. Instead of Bits<8><4>, try defining CRF as a simple Bits<32> alias first, and then introduce slicing operations later in the code. This can help determine if the issue lies specifically with the multi-dimensional alias definition.
  4. Inspect the sub(BitsType, BitsType) Built-in Call: The error message also mentions BuiltInCall<Bits<5>, VADL::sub(BitsType, BitsType) -> BitsType>. This suggests that the slicing operation might be using a subtraction function (sub) to calculate the slice offset or length. Inspect the implementation of this built-in function to ensure it handles edge cases and potential null values correctly.
  5. Check for Viam Graph Bugs: It's possible that this error exposes a bug in the Viam Graph library itself. Search the Viam Graph issue tracker or forums for similar reports. If a bug is confirmed, consider submitting a bug report with a minimal reproducible example (the provided code snippet is a good starting point).
  6. Use a Debugger: If possible, use a debugger to step through the Viam Graph's code execution when processing the VADL specification. This can provide invaluable insights into the graph's internal state and how nodes are being applied. Pay close attention to the DynSliceNode and the sub function calls.
  7. Consider Alternative Alias Implementations: If the Viam Graph has alternative mechanisms for defining register aliases, explore those options. There might be a different way to achieve the desired aliasing behavior without triggering the error. For example, consider using bitfield definitions if they are supported.

A Step-by-Step Approach to Resolving the Error

Here’s a suggested step-by-step approach to tackle this issue:

  1. Reproduce the Error Consistently: Ensure that you can consistently reproduce the error with the provided VADL code snippet. This is the foundation for effective debugging.
  2. Simplify the Code (Stepwise): Start removing parts of the code to identify the minimal code required to reproduce the error. For example:
    • Remove the memory region definition.
    • Remove the reset assignment.
    • Change the alias definition to alias register CRF : Bits<32> = CR.
    • If the error disappears after one of these steps, you’ve narrowed down the problematic area.
  3. Focus on the DynSliceNode: Since the error message points to the DynSliceNode, dedicate your investigation to this node’s implementation. Look for potential null value handling issues.
  4. Inspect the sub Function: Examine how the sub function is used in the slicing operation. Ensure it doesn't produce unexpected results.
  5. Consult Viam Graph Documentation and Community: Review the Viam Graph documentation for best practices on defining register aliases and slicing operations. Search the Viam Graph community forums or issue tracker for similar issues.
  6. Prepare a Minimal Reproducible Example: If you suspect a bug in the Viam Graph library, create a minimal reproducible example (the simplest possible VADL code that triggers the error) and submit it as a bug report.

Example of Simplifying the Code

Let's illustrate the simplification approach. First, try commenting out the memory region and reset lines:

instruction set architecture ARCH = {

  program counter PC  : Bits<64>
  memory          MEM : Bits<64> -> Bits<8>

  register CR  : Bits<32>
  alias register CRF : Bits<8><4> = CR

}

processor EXAMPLE implements ARCH = {
  //reset = PC := 0x0000'0000'0000'0000

  //[ firmware ]
  //[ base: 0x00000000 ]
  //memory region [RAM] DRAM in MEM
}

If the error persists, the issue is likely within the architecture definition itself. Next, try simplifying the alias definition:

instruction set architecture ARCH = {

  program counter PC  : Bits<64>
  memory          MEM : Bits<64> -> Bits<8>

  register CR  : Bits<32>
  alias register CRF : Bits<32> = CR // Simplified alias

}

processor EXAMPLE implements ARCH = {
  //reset = PC := 0x0000'0000'0000'0000

  //[ firmware ]
  //[ base: 0x00000000 ]
  //memory region [RAM] DRAM in MEM
}

If the error disappears now, it strongly suggests that the issue lies with the multi-dimensional slicing in the original alias definition (Bits<8><4>).

Conclusion

The vadl.viam.graph.ViamGraphError encountered when registering an alias in ISS highlights the complexities of graph-based systems and the importance of careful null value handling. By systematically debugging and simplifying the code, focusing on the DynSliceNode, and consulting Viam Graph resources, you can effectively identify and resolve this issue. Remember to create a minimal reproducible example if you suspect a bug in the Viam Graph library itself. Understanding the intricacies of VADL and the Viam Graph will empower you to design robust and efficient instruction set simulators.

For further information on Viam and its architecture description language, consider exploring the official Viam documentation.
